RAYX

Authors: Peter Feuer-Forson, Peter Baumgärtel, Sven Erdem, Fanny Zotter, Jannis Meier

Keywords: Synchrotron, Python, Open source, X-ray, C++, Ray tracing, Radiation

RAYX is a simulation tool for beamlines at electron storage rings. It traces synchrotron radiation through a series of mirrors, gratings and more and provides the user with helpful insights, how a given beamline performs.

Publications

hz-b/rayx: v1.1.0

Zenodo - 2025

10.5281/zenodo.16902390

RAYX—An optics simulation software for synchrotron applications

Erdem S, Feuer-Forson P, Maier J, Möller F, Ahlers E, Stöcker V, Zotter F, Baumgärtel P, Viefhaus J - Review of Scientific Instruments - 2025

10.1063/5.0253857

Helmholtz RSD

This entry is synchronized with the Helmholtz Research Software Directory (RSD).
If you're the author or maintainer, please edit on the Helmholtz RSD platform.
Click here to view RAYX on RSD.

Logo of RAYX

©RAYX

Weblinks

helmholtz.software/software/rayx

License

MIT
